Article number:

5293984

Its updated slacker frame geometry makes it easier to control on descents while the upgraded suspension fork takes the edge off bumpy trails. Integrated rack and kickstand mounts make it easy to add accessories to this versatile steed.

You want a trail bike that’s dialled for building confidence on the dirt, and versatile enough for commuting to work or school.

A lightweight aluminium frame with modern trail riding geometry and internal routing that keeps cables protected and keeps the bike looking sleek. A 100 mm RockShox Judy front suspension fork that cushions rocks, roots and bumps in the trail, 10-speed fuss-free Shimano CUES shifting and the serious stopping power of hydraulic disc brakes.

The Marlin 6 is an ideal trail bike for riders who want to progress on the dirt, and want a bike that can keep them rolling off of the trail, too.

The Marlin Gen 3 gives you serious trail capability with bigger tyre clearance, internal dropper post routing, ThruSkew rear axle and longer, slacker geometry that gives you more stability on steeper trails and at higher speeds
Its RockShox fork gives you 100 mm of suspension for turning rocks and roots on the trail into smooth-sailing
Rack and mudguard mounts make it easy to accessorise, so your mountain bike can double as a rugged commuter
Internal routing makes it easy to add a dropper post that lets you lower your saddle on the fly for more confident descending
Marlin models in sizes XXS and XS have a curved top tube and lower standover height that makes it easier for smaller riders to mount and dismount

*Frame	Size: XS Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew
*Frame	Size: S , M , ML , L , XL , XXL Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew
*Fork	Size: XS , S RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5″ wheel, 100 mm QR, 100 mm travel
*Fork	Size: M , ML , L , XL , XXL RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel
Max compatible fork travel	120mm, XXS: 80mm

Hub front	Formula DC-20, alloy, 6-bolt, 100 mm ThruSkew
Hub rear	Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm QR
Rim	Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
*Tyre	Size: XS , S Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 27.5×2.35″
*Tyre	Size: M , ML , L , XL , XXL Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 29×2.35″
Max tyre size	Frame: 29×2.40″ (XXS: 26×2.40″, XS & S: 27.5×2.40″), Fork: See manufacturer

Shifter	Shimano U6000, 10-speed
Rear derailleur	Shimano CUES U6000 GS
*Crank	Size: XS FSA Alpha Drive, 30T, 160 mm length
	Size: S , M , ML FSA Alpha Drive, 30T, 170 mm length
	Size: L , XL , XXL FSA Alpha Drive, 30T, 175 mm length
Bottom bracket	FSA, 73 mm, threaded cartridge, 122.5 mm spindle
Cassette	Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain	Shimano LG500
Pedal	VP-536 nylon platform
Max. chainring size	1x: 34T, 2x: 36/22

Saddle	Bontrager Verse Short, stainless steel rails
*Seatpost	Size: XS , S , M Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
*Seatpost	Size: ML , L , XL , XXL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar	Size: XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
	Size: S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
	Size: M , ML , L , XL , XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips	Bontrager XR Trail Comp, nylon lock-on
*Stem	Size: XS , S Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 35 mm length
	Size: M , ML , L Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
	Size: XL Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
	Size: XXL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Head set	Semi-integrated, 1-1/8″
Brake rotor	Tektro, 6-bolt, 160mm
*Brake Set	Size: XS , S Tektro HD-M276 hydraulic disc, short reach
*Brake Set	Size: M , ML , L , XL , XXL Tektro HD-M275 hydraulic disc
Rotor size	Max brake rotor sizes – Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer

Weight	M – 14.50 kg / 31.97 lbs (with tubes)
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
